600 Amp, 38 KV, POWERCON PIF LOAD BREAK INTERRUPTER SWITCH   Our stock number: 44948

600 Amp, 38 KV, POWERCON PIF LOAD BREAK INTERRUPTER SWITCH

Click on picture below for larger version
600 Amp, 38 KV, POWERCON PIF LOAD BREAK INTERRUPTER SWITCH600 Amp, 38 KV, POWERCON PIF LOAD BREAK INTERRUPTER SWITCH



CB-19642

One (1) 600 Amp PowerCon Load Break Interrupter Switch
Type PIF
Model 571-99
NEMA 3R Enclosure
23 KV Nominal
38 KV Max
150 KV BIL
600 Amp Main Bus
60 HZ
40 KA Asym. Momentary
40 KA Asym. Fault and Close
3 Phase
Unfused

Overall & Shipping Dims: 135"H x 155"W x 71"
Individual Switch Dims: 135"H x 60"W x 71"D
Incoming Section Dims: 135"H x 36"W x 71"D
Overall & Shipping Weight: 4,200 Lbs
