CB-19495

ONE (1) 1200 AMP SQUARE D VACUUM SUBSTATION CIRCUIT BREAKER
TYPE FVR1121120A
17 KV MAX
110 KV BIL
60 HERTZ
50 KV RMS
3 CYCLE INTERRUPT
54 KA CLOSE & LATCH
20 KA SHORT CIRCUIT
125 VDC TRIP
240 VAC CLOSE
240 VAC CHARGING MOTOR
6 X 1200:5 MRCT CLASS C400
MFG. 2008
71 OPERATIONS
S/N 21476
2000 LBS
6065-01 MAINTENANCE MANUAL
C25295425-001-01 CONTROL DIAGRAM
