General Specifications per Manufacturer brochure:

Basket Size: .......................... 18" x 24"
Basket Capacity: ...................... 250 lbs
Motor: ................................ 3 HP
RPMs: ................................. 625
Voltage (standard): ................... 230Vor 460V, 3 Ph, 60 Hz (specify)
Amperage: ............................. 13.4 (approx)
Bearings: ............................. Tapered Roller
Reversable: ........................... Yes
Control Drive: ........................ 2 V-Belts


Dimension (approx): ................... 31" x 40" x 46.5"
Weight (approx): ...................... 690 lbs

Options (prices subject to change without notice):

Baskets (not included with new unit):
Polyethylene: ..................$1750  (3/16" mesh size)
SS 304: ........................$2150  *
Carbon Steel: ..................$1150  *
* 1/4"or 1/8" perforation openings available - specify
Drop Bottom Baskets available in Carbon Steel  add $650/basket
                                 SS 304        add $950/basket

Soft Start: ....................$3666
Timer: .........................$1440

Alternative Voltages: ..........$ POR
