Specifications from OEM brochure and equipped with are described to the best

of our knowledge. ALL items should be verified by buyer.

Equipped With:
   Control Cabinet
   6-Processing Stations
   Load & Off-Load Station
   Rigibot Transfer System

General Specifications
   Station #1:       Load Conveyor
   Station #2        Ultrasonic Wash; 58x20x22"D tank
                     8000W @ 40KHz, heaters 16KW
                     10GPM Recirc, 25 Micron Bag Filter, 10 Micro Cat Filter
   Station  #3:      Ultrasonic Wash; 29x20x23"D tank
                     4000W @ 40KHz, heaters 9KW
                     10 GPM Recirc, 25 Micron Bag Filter, 10 micron Cat Filter
   Station #4 & #5:  Ultrasonic Rinse; 29x20x23"D tank
                     4000W @ 40KHz
                     12KW Heater
   Station #6:       Steam Rinse; 29x20x22"D
   Station #7:       Dryer with Power Lid;
                     3600 cfm Blower, 20kw Heater
   Staiton #8:       Unload Conveyor

Overall length of unit w/ control:        441"L x 55"D x 84"H

====================================

Information collected from Crest:

What frequency are the ultrasonic generators capable of?  The system has 40

kHz.  Other frequencies 58 and 132 kHz could be used but tanks and generators

would need replacement.

Can they accommodate multi frequency sweep recipes/programs?  All frequencies

mentioned are the resonate frequencies built for the specific transducer.  The

generator sweeps the frequency around the resonance +/- 2kHz to prevent

standing waves.

What chemistry or process was on the system previously (what chemicals were

used, what decontamination was completed)?  The system used an alkaline PH 10

cleaner designed to split off oil residual.  There is not a specific concern

related to residual.  The system only needs a good flushing and should be

ready to go for a new chemistry to be used.
