14", KALAMAZOO CT350ANC, 2003, Vacuum Chip Removal, Parts Counter, CNC   Our stock number: 394248

14 , KALAMAZOO CT350ANC, 2003, Vacuum Chip Removal, Parts Counter, CNC

Click on picture below for larger version
14 , KALAMAZOO CT350ANC, 2003, Vacuum Chip Removal, Parts Counter, CNC14 , KALAMAZOO CT350ANC, 2003, Vacuum Chip Removal, Parts Counter, CNC14 , KALAMAZOO CT350ANC, 2003, Vacuum Chip Removal, Parts Counter, CNC14 , KALAMAZOO CT350ANC, 2003, Vacuum Chip Removal, Parts Counter, CNC

Specification from OEM Brochure (All details should be confirmed by buyer)

Blade diameter:                                350 mm (14.28")
Blade motor:                                   3 HP
Blade Speed:                                   3600 RPM
Max. vise opening:                             8"
Cutting capacities
Round tube @ 90 degrees:                       4.75"
Round tube @ 45 degrees(right/left):           4.5"
Round tube @ 60 degrees:                       3.0"
Sq. tube @ 90 degrees:                         4.5"
Sq. tube  @ 45 degrees(right/left):            4"
Sq. tube @ 60 degrees:                         2.75"
Rect. Tube @ 90 degrees:                       7.5" x 3.5"wide
Rect. Tube @ 45 degrees(right/left):           5.9" x 2.75"
Rect. Tube @ 60 degrees:                       7.0" x 2.25"

Automatic Feed Lengths:                        1/8" to 20" (with 1 feed)
                                               1/8" to infinite (w/multi feed)
Feeding accuracy:                              +/- .005"
Machine:  98" x 52" x 77" 1,600 lbs
